PRODUCT FEATURES | |
| |
4'' rapid response capacitive touchscreen Quick set sampling specifications Supports remote sampling | One-click report export and printing Wireless connection with the APC and BAMS to support triggered sampling |
| |
Long Battery Life | Flow Accuracy |
100L/min≥10hours (60m³） | ±2.5%（100L/min） |
| |
Compliance with FDA21 CFR Part 11 | |
REMOTE SAMPLING | |
| |
| |
APPLICATIONS | |
| |
| When performing isokinetic sampling, the sampler is designed so that the airflow direction into the inlet of the sampling head is consistent with the average velocity of the unidirectional flow through the sampling head |
| |
| Compressed gas is decompressed to atmospheric pressure by the High Pressure Diffuser (HPD) and transported to the BioAerosol Sampler-Economic for sampling |
SPECIFICATIONS
FLOW RATE： 100L/min
FLOW RATE ACCURACY： ±2.5%（100L/min)
SAMPLING VOLUMES： 1-6,000L
DELAY： 0-23 hours 59 minutes 59 seconds
SAMPLING HEAD： Φ0.60mm*280holes (100L/min)
DIMENSIONS (HxWxD)： 218x120x120mm/ 8.58x4.72x4.72 in (without foot mat)
WEIGHT： 2.9kg (6.4lbs)
EXTERNAL SURFACE： Anodized aluminium
POWER： 24V±10% AC adapter
BATTERY： 10.8V, 6800mAh rechargeable lithium battery, running for over 10 hours
DATA STORAGE： 20,000 sets of sample records
DISPLAY： 4" capacitive touch screen
LANGUAGE： Chinese, English
CALIBRATION FREQUENCY： Recommend once a year
OPERATING CONDITIONS：5-35℃(41-95℉), 5-90%RH non-condensing
STORAGE CONDITIONS： 0-40℃(32-104℉), 5-95%RH non-condensing
SAFETY： EN 61010-1:2010+A1:2019, EN 61326-1:2013, EN IEC 61326-1:2021, EN 61000-6-1:2007, EN 61000-6-3:2007+A1
WARRANTY： 24 months (calculated from the date of product activation or 6 months after the date of manufacture, whichever comes first)
